Product Description
The Square D QO230EPD is a miniature circuit breaker that provides overcurrent protection and switching on AC and DC systems. This 2-pole QO circuit breaker is rated at 30A at 120/240VAC with a 10kA breaking capacity and plug-in mounting. It features an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. Includes 30mA ground fault B protection.
- Overcurrent protection
- Switching on ac and dc systems
- Over center, trip free toggle mechanism
- Quick make, quick break action
- Positive handle indication
- VisiTrip trip indication
- 30mA ground fault B protection
Product Highlights
Provides reliable overcurrent, short circuit protection and switching on AC and DC systems. UL Listed and CSA Certified.
Product Information
Standard Information
-
Brand: SQUARE D
-
Manufacturer Part Number: QO230EPD
-
Country of Origin: Mexico
Technical Specifications
-
Type: Miniature circuit-breaker
-
Brand: Square D
-
Current: 30 Amp
-
Voltage: 120 Volt
-
Amperage: 30 Amp
-
Sub Brand: QO
-
Wire Size: AWG 14...AWG 8 copper;AWG 12...AWG 8 aluminium NULL
-
Mounting Type: Plug-in
-
Certifications: CSA,UL Listed
-
Conductor Size: 12-8 AWG (AL)/14-8 AWG (CU)
-
Number of Poles: 2 Pole
-
Interrupt Rating: 10KA kA
-
Country of Origin: Mexico
-
Line Rated Current: 30 A
-
Circuit Breaker Type: Ground Fault Protecting Class B 30 MA
-
Operating Temperature: 40 °C
-
Short Circuit Current: 10 kA
-
Voltage Rating: 120/240 VAC
-
Trip Sensitivity: 30 Milliampere
-
Terminal Type: Pressure Plate
-
Mounting: Plug-On
-
Used On: QO Loadcenter, NQOD Panelboard, OEM Interior/Speed-D Switchboard Distribution Panel
-
Approval: UL, CSA
-
Application: Provides Overload and Short Circuit Protection
-
Poles: 2-Pole
-
Protection: Equipment Protection Device
-
Ground Fault Protection: 30mA ground fault B protection
-
Item: Miniature Circuit Breaker
-
Phase: Single
-
Series: QO
-
Features: Mercury Free
-
Standards: CSA Certified, UL Listed
-
Curve Type: B
-
Frame Size: 100A/QO
-
For Use With: QO Load Centers and NQ Panelboards
-
Product Type: Miniature Circuit Breaker
-
Max. Wire Size: 8 AWG
-
Min. Wire Size: 12 AWG (Al), 14 AWG (Cu)
-
Max. AIR Rating: 10kA at 120/240V AC
-
AC Voltage Rating: 120/240V AC
-
DC Voltage Rating: Not Rated
-
Terminal Connection: Pressure plate
-
Circuit Breaker Actuator: Paddle
-
Compatible Panelboard/Load Center Series: NQ, QO
-
Electrical Connection: Pressure plate
-
Inturrupt Rating: 10 kA at: 120/240 V AC 50/60 Hz, 10 kA at: 120 V AC 50/60 Hz
-
Number of Panel Spaces: 2
-
Ambient Rating: 104 Degree F (40 Degree C)
-
Connection type: Pressure Plate
-
Mounting type: Plug-On
-
Frequency: 60 Hz
-
Interrupt: 10 kA
-
Trip: Thermal Magnetic Trip
-
Temperature: 104 deg F
-
Alternate Catalog Number: QO230EPD
-
Amperage Rating: 30 A
-
ARRA Compliant: N
-
Buy American Compliant: N
-
Catalog Number: QO230EPD
-
Connection: PRESSURE PLATE #12 TO #8 AWG(AL) - #14 TO #8 AWG(CU)
-
EU RoHS Indicator: Y
-
Harmonization Tariff Schedule Code: 8536200040
-
Manufacturer: Schneider Electric
-
Standard: UL LISTED - CSA CERTIFIED
