Square D QO2301042 2-Pole 30 Amp Miniature Circuit Breaker

Product Description

The Square D QO2301042 is a 2-pole thermal magnetic circuit breaker that provides overcurrent protection and switching on AC and DC systems. It features an over center, trip-free toggle mechanism with quick make, quick break action, and positive handle indication, as well as VisiTrip trip indication. Rated at 30A at 120/240VAC with a 10kA breaking capacity and plug-in mounting, it includes an AC/DC shunt trip.

• Provides overcurrent protection
• Enables switching on AC and DC systems
• Features VisiTrip trip indication

Product Highlights

This 2-pole QO circuit breaker is rated at 30A at 120/240VAC and provides 10kA breaking capacity with plug in mounting. Includes an AC/DC shunt trip.

Product Information

Standard Information

• Brand: SQUARE D
• Manufacturer Part Number: QO2301042
• Country of Origin: Mexico

Technical Specifications

• Type: Miniature circuit-breaker
• Brand: Square D
• Depth: 74 mm
• Width: 57 mm
• Height: 76 mm
• Length: 2.91 Inch
• Current: 30 Amp
• Voltage: 120 Volt
• Amperage: 30 Amp
• Material: Fiberglass
• Sub Brand: QO
• Wire Size: AWG 14...AWG 8 copper or aluminium NULL
• Applications: HACR rated
• Mounting Type: Plug-in
• TC Connection: Pressure plate
• Certifications: CSA,UL Listed
• Conductor Size: 14-8 AWG
• Number of Poles: 2 Pole
• Interrupt Rating: 5, 10 kAIC
• Country of Origin: Mexico
• Line Rated Current: 30 A
• Circuit Breaker Type: Standard
• Operating Temperature: CALIBRATED FOR USE AT 40 DEGREES C. SEE DATA BULLETIN 0100DB0101 FOR RE-RATING INFORMATION.
• Short Circuit Current: 10 kA
• Manufacturer: Schneider Electric
• UPC: 785901088271
• GTIN: 00785901088271
• MPN: QO2301042
