Product Description
The Square D QO200 is a 2-pole thermal magnetic circuit breaker designed for overcurrent protection and switching on AC and DC systems. It features a trip-free toggle mechanism with quick make, quick break action and positive handle indication. The VisiTrip trip indication provides a visual alert when the circuit breaker has tripped. Rated at 60A at 240VAC with a 10kA breaking capacity and plug-in mounting.
- Provides overcurrent protection and switching on AC and DC systems.
- Features a trip-free toggle mechanism with quick make/break action.
- Includes VisiTrip trip indication for visual alerts.
Product Highlights
This 2-pole QO mini switch is rated at 60A at 240VAC and offers 10kA breaking capacity with plug-in mounting. UL listed and CSA certified.
Product Information
Standard Information
-
Brand: SQUARE D
-
Manufacturer Part Number: QO200
-
Country of Origin: Mexico
Technical Specifications
-
Type: Miniature, Common Trip, Molded Case
-
Brand: Square D
-
Range: QO NULL
-
Current: 60 Amp
-
Voltage: 240 VAC
-
Amperage: 60 Amp
-
Sub Brand: QO
-
Wire Size: 8 to 2 AWG (Aluminum/Copper)
-
Product UPC: 78590137170
-
12-Digit UPC: 785901371700
-
Applications: QO
-
Mounting: Plug-On
-
Mounting Type: Plug-In
-
Terminal Type: Box Lug
-
TC Connection: AWG 8...AWG 2 COPPER OR ALUMINIUM,BOX LUGS
-
Certifications: CSA,UL Listed
-
Conductor Size: 8-2 AWG
-
Number of Poles: 2
-
Interrupt Rating: 10 kAIC
-
Country of Origin: Mexico
-
Line Rated Current: 60 A
-
Short Circuit Current: 10 kA
-
Manufacturer: Schneider Electric
-
UPC: 785901371700
-
GTIN: 00785901371700
-
Series: QO
-
Features: Mercury Free
-
Standards: UL Listed, CSA
-
Product Type: Nonautomatic Miniature Switch 240V 60A
-
Max. Wire Size: 2 AWG (Cu/Al)
-
Min. Wire Size: 8 AWG (Cu/Al)
-
Max. AIR Rating: 10 kA
-
AC Voltage Rating: 240VAC
-
Terminal Connection: Box Lugs
-
Circuit Breaker Mounting Style: Plug-In
-
Interrupting Rating: 10 Kiloampere
-
Used On: QO Loadcenter, NQOD Panelboard, NQOD OEM Interior, Speed-D Switchboard Distribution Panel
-
Approval: UL, CSA
-
Voltage Rating: 120/240VAC, 48VDC
-
Poles: 2
-
Phase: 1
-
AIC Rating: 10kA @ 120/240VAC, 5kA @ 48VDC
-
For Use With: QO Load Centers, NQ Panelboards, NQOD Panelboards
-
Wire Gauge: 8-2 AWG (Al/Cu)
-
Max Wire: 2 AWG
-
Min Wire: 8 AWG
-
Available Options: Shunt Trip, Auxiliary Switch, Alarm Switch
-
Temp Rating: 40C
-
Construction Features: Non-Automatic (Disconnect), Visual Trip Indicator
