Square D QO142M225PRB Main Breaker Load Center 225A 1 Phase NEMA 3R

Product Description

The Square D QO142M225PRB is a convertible main breaker load center rated at 225 Amps and designed for both residential and industrial applications. Its configuration allows for installation of QO breakers, ground fault interrupters, arc fault interrupters, and surge arresters. The load center features a NEMA 3R weatherproof enclosure suitable for outdoor use, ensuring the safety of electrical systems and equipment.

• Rated for 225 Amps and 120/240 Volts
• Configured with 42 spaces and 52 circuits
• Includes plug-on neutral design for easy installation

Product Highlights

This load center supports a full array of accessories, allowing for increased functionality. Designed for single-phase applications, it features tin-plated copper bus bars for enhanced conductivity and reliability.

Product Information

Standard Information

• Catalog Number: QO142M225PRB
• Manufacturer: Schneider Electric

Technical Specifications

• Enclosure Type: NEMA 3R
• Current Rating: 225 A
• Number of Phases: 1
• Number of Spaces: 42
• Number of Circuits: 52
• Weight: 18.600 kg
• Country of Origin: Mexico
• UL Listed: Yes
