Square D QO130EPD Miniature Circuit Breaker w/GFI 30A 120V 1Ph 1P

Product Description

Square D QO130EPD is a miniature circuit breaker with GFI, rated for thirty amps at one hundred twenty volts. This device is designed to provide overcurrent protection in both AC and DC systems. It features a quick make and break action with positive handle indication. The breaker includes VisiTrip trip indication, showing when the circuit has interrupted. The unit features plug-in mounting for easy installation.

• Current Rating: 30 Amps
• Voltage Rating: 120 Volts
• Interrupt Rating: 10 kAIC

Product Highlights

This miniature circuit breaker is part of the QO series, known for its reliability and safety features.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Square-D / Schneider

Technical Specifications

• Type: Miniature circuit-breaker
• Depth: 2.91 inches
• Width: 19 mm
• Height: 105 mm
• Current: 30 Amp
• Voltage: 120 Volt
• Mounting Type: Plug-in
• Certifications: CSA, UL Listed
• Wire Size: AWG 14...AWG 8 copper; AWG 12...AWG 8 aluminum
• Warranty Length: 18 months
