Square D QO124M125PRB 125A 120/240V 1 Phase Convertible Main Breaker Load Center, Plug-On Neutral, 24 Spaces / 34 Circuits

Product Description

The Square D QO124M125PRB is a 125Amp 120/240V one-phase convertible main breaker load center. This load center supports both traditional and plug-on neutral configurations. It includes space for twenty-four circuits and thirty-four poles. The NEMA-3R enclosure offers weatherproof protection for both indoor and outdoor applications.

• Integrated with QO breakers and ground fault interrupters.
• UL rated for safety and reliability.
• Easy to install with shielded tin-plated copper bus bars.

Product Highlights

This load center is ideal for residential and light industrial installations, providing comprehensive protection for electrical systems and equipment.

Product Information

Standard Information

• Brand: Square D
• MPN: QO124M125PRB

Technical Specifications

• Current Rating: 125 Amps
• Voltage: 120/240 Volts
• Number of Spaces: 24
• Number of Circuits: 34
• Enclosure Type: NEMA 3R
• Height: 22.06 inches
• Width: 14.75 inches
• Depth: 4.52 inches
