Square D QO115HM 1-Pole 15 Amp 120/240 Volt Plug-On Thermal Magnetic Miniature Circuit Breaker

Product Description

Square D QO115HM is a one pole, 15 amp thermal magnetic miniature circuit breaker. It operates on both alternating and direct current systems. This circuit breaker features a quick make and break toggle mechanism that indicates whether the circuit is engaged. The product includes VisiTrip technology, which offers a visual trip indication to show that the circuit has been interrupted.

• Rated at 15 amps, suitable for 120 volts.
• 10 kA interrupting capacity.
• Plug-in mounting for easy installation.

Product Highlights

The Square D QO115HM provides reliable overload and short circuit protection. It is ideal for applications with high initial inrush currents.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: QO115HM
• Current Rating: 15 Amp
• Voltage Rating: 120 Volt
• Number of Poles: 1 Pole
• Interrupting Capacity: 10 kAIC
• Mounting Type: Plug-in
• Physical Dimensions: Length two point nine one inches, Width nineteen millimeters, Height seventy-six millimeters
• Country of Origin: Mexico
