Square D QBL22200 Molded Case Circuit Breaker 200A 240V 2P

Product Description

The Square D QBL22200 Molded Case Circuit Breaker is designed for overcurrent protection in electrical systems. This unit is rated for 200 Amperes and operates at a voltage of two hundred forty Volts. It features a thermal-magnetic trip mechanism which provides reliable protection against overloads and short circuits.

• Two-pole design rated for 200 Amperes and 240 Volts
• Thermal-magnetic trip unit for efficient circuit management
• Suitable for unit mount or I-Line group mounting

Product Highlights

This circuit breaker complies with UL, CSA, and IEC standards, ensuring safe operation in a variety of applications. The product is intended for use in commercial and industrial environments, providing dependable protection for circuits.

Product Information

Standard Information

• Catalog Number: QBL22200
• Brand: Square D

Technical Specifications

• Voltage: 240 Volt
• Amperage: 200 Amp
• Standard: CSA, NEMA, NOM-003-SCFI-2000, UL
• Trip Type: Thermal-magnetic
• Number of Poles: 2 Pole
• Height: 6.47 Inch
• Width: 3.00 Inch
• Depth: 3.93 Inch
