Square D LAL36300MB 3-Pole 300 Amp 600 Volt Thermal Magnetic Molded Case Circuit Breaker

Product Description

This Square D LAL36300MB is a three-pole, 300 Amp circuit breaker designed for thermal magnetic protection. It automatically opens in case of overload or short circuit conditions, and can also be manually opened. The circuit breaker has thermal and magnetic sensors built into each pole, providing efficient operation. The Push-to-Trip feature allows manual tripping without contact with live components.

• Three-pole design for effective circuit management.
• Interrupting rating: 22kA at 600VAC, 10kA at 250VDC.
• UL, CSA, and IEC certified for safety and performance.

Product Highlights

Ideal for low voltage power distribution needs, this circuit breaker is equipped with a shorter handle, allowing for panel door closure without obstruction. It is suitable for various applications, ensuring reliable circuit protection.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: LAL36300MB
• Rated Current: 300 Amp
• Voltage: 600 Volt
• Number of Poles: 3
• Trip Type: Thermal Magnetic
• Height: 11 inches
• Width: 6 inches
• Depth: 5.84 inches
• Country of Origin: Mexico
• Warranty Description: 18 months
• Interrupting Rating: 22kA, 10kA
