Square D JD250S Circuit Breaker Enclosure Power 150/250 Amp

Product Description

Square D offers the JD250S circuit breaker enclosure, designed for PowerPact circuit breakers. This enclosure is rated for NEMA 1 usage and supports circuit breakers with a current rating from fifteen to two hundred fifty amps. It ensures reliable performance for a wide range of applications.

• Accommodates up to three pole circuit breakers
• Constructed from steel for durability
• Certifications include CSA and UL

Product Highlights

This enclosure is suitable for service entrance installations with the necessary assembly. It is designed to meet short circuit current ratings equal to the installed circuit breaker’s rating, ensuring safety and compliance.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: JD250S
• Current Rating: 250 Amps
• Enclosure Material: Steel
• Dimensions: 13.75 x 4.33 x 40.5 inches
• Warranty Length: 18 months
• Number of Poles: 3 Pole
• Country of Origin: United States
• Mounting Type: Surface
