Square D HOMT2020240 Homeline Tandem Plug-In Circuit Breaker, (1) 20A (2) 40A, 120/240VAC, 2-Pole

Product Description

The Square D HOMT2020240 Homeline miniature circuit breakers are engineered for fast installation and superior circuit protection. Designed to plug into Homeline load centers, this quad tandem breaker occupies two HOM pole spaces. It consists of a two pole breaker in the middle and a single breaker on each side, providing standard circuit protection and is HACR rated.

• Engineered and designed for fast installation
• Superior circuit protection
• Plugs into Homeline load centers

Product Highlights

This Square D HOMT circuit breaker is a quad tandem breaker with a voltage rating of 120/240 VAC and interrupt rating of 10 kAIC.

Product Information

Standard Information

• Brand: SQUARE D
• Manufacturer Part Number: HOMT2020240
• Country of Origin: United States

Technical Specifications

• UPC: 785901377047
• Type: Plug In - Tandem Breakers
• Depth: 2.98 Inches
• Width: 2 Inches
• Height: 3.13 Inches
• Material: Thermoplastic
• Standard: UL 498
• Trip Type: Thermal Magnetic
• Connection: Screw terminal
• Voltage Rating: 120/240 VAC
• Amperage Rating: 20/(2)40/20 Amperes
• Number Of Poles: 2-Pole
• Frequency Rating: 50/60 Hertz
• Interrupt Rating: 10 kAIC
• Country of Origin: MX
• Mounting Type: Plug-in
• Certifications: UL
• Conductor Size: 12-6 AWG (AL)/14-6 AWG (CU)
• Number of Spaces: 2
• Line Rated Current: 20 A
• Circuit Breaker Type: Quad Tandem
• Short Circuit Current: 10 kA
• Brand: Square D
• Manufacturer: Schneider Electric
• GTIN: 00785901377047
• Voltage: 120/240 Volt
• Current: 20 Amp
• Mounting: Plug-On
• Terminal Type: Screw Clamp
• Wire Size (Copper): AWG 14...AWG 6
• Wire Size (Aluminum): AWG 12...AWG 6
• Wire Size (Aluminum 2): AWG 12...AWG 8
• Product: Miniature circuit-breaker
• Range: Homeline
• Current Rating: 20 A & 40 A
• Electrical Connection: Box lugs
• Poles Description: 2P || 1P
• [Ue] Rated Operational Voltage: 120/240 V AC
• Awg Gauge: 1 x AWG 14...AWG 6 ( copper ) || 1 x AWG 12...AWG 6 ( aluminium ) || 1 x AWG 12...AWG 8 ( aluminium )
• Used On: Homeline Loadcenter
• Approval: UL, CSA
• Item: Miniature Circuit Breaker
• Series: HOM
• Features: Mercury Free
• Standards: UL Listed
• Application: HACR rated Applications
• Product Type: Miniature Circuit Breaker 120/240V 20A
• Max. Wire Size: 6 AWG (Cu/Al), 8 AWG (Al)
• Min. Wire Size: 14 AWG (Cu), 12 AWG (Al)
• AC Voltage Rating: 120/240VAC
