Square D HOMT2020230 Miniature Circuit Breaker 20 Amp 120/240 Volt

Product Description

The Square D HOMT2020230 is a miniature circuit breaker designed for 120/240 volt applications. This 20 amp breaker works with Homeline load centers, supporting efficient circuit protection.

• Quad tandem design using two pole and single pole breakers.
• 10 kA breaking capacity ensures reliable circuit protection.
• Accepts copper or aluminum wire from 14 AWG to 8 AWG.

Product Highlights

Suitable for residential and light commercial use. It is HACR rated and UL Listed for safety and reliability.

Product Information

Standard Information

• Catalog Number: HOMT2020230
• Brand: Square D

Technical Specifications

• Voltage Rating: 120/240 Volt
• Current Rating: 20 Amp
• Number of Poles: 1-2 Pole
• Breaking Capacity: 10 kA
• Dimensions: 3.13 inches tall, 2.00 inches wide, 2.98 inches deep
• Wire Size Compatibility: 14 AWG to 8 AWG copper or aluminum
• Mounting Type: Plug-in
• Country of Origin: Mexico
