Square D HOMT2020220 Miniature Circuit Breaker 120/240 Volt 20 Amp

Product Description

The Square D HOMT2020220 is a miniature circuit breaker designed for use in residential electrical systems. This breaker operates at 120/240 volts and has a current rating of 20 amps. It is compatible with Homeline load centers, providing reliable protection from overload and short circuits.

• Two pole design with one single pole on each side
• 10 kA breaking capacity
• Accepts 14 AWG to 8 AWG copper or aluminum wire

Product Highlights

This quad tandem breaker occupies two pole spaces and includes a two pole breaker in the center, along with two single pole breakers. This configuration is HACR rated, suitable for HVAC loads. The dimensions are 3.13 inches tall, 2 inches wide, and 2.98 inches deep. UL listed for safety and reliability.

Product Information

Standard Information

• Catalog Number: HOMT2020220
• Manufacturer: Schneider Electric

Technical Specifications

• Brand: Square D
• Current: 20 Amp
• Voltage: 120/240 Volt
• Breaker Type: Quad Tandem
• Number of Poles: 1-2 Pole
• Short Circuit Current Rating: 10 kA
• Warranty Length: Lifetime
• Country of Origin: Mexico
