Square D HOMT1515240 Square D 120/240 Volt 15 Amp Miniature Circuit Breaker

Product Description

The Square D HOMT1515240 is a 120/240 volt 15 amp miniature circuit breaker designed for quick installation and reliable overload protection. This quad tandem circuit breaker fits into Homeline load centers, occupying two pole spaces with a dual-pole breaker in the center and single-pole breakers on the sides. The circuit breaker has a breaking capacity of 10 kA, ensuring effective protection for your electrical system.

• HACR rated for HVAC applications
• Compatible with AWG wire sizes from fourteen to six for copper and twelve to six for aluminum
• UL Listed for safety compliance

Product Highlights

Ideal for residential use, this breaker features a straightforward installation process.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: HOMT1515240
• Current Rating: 15 Amp
• Voltage Rating: 120/240 Volt
• Wire Size: AWG 14 to AWG 8 for aluminum/copper, AWG 14 to AWG 6 for copper
• Number of Poles: Quad Tandem (2 Pole + 2 Single Pole)
• Short Circuit Current Rating: 10 kA
• Country of Origin: Mexico
• Warranty Length: Lifetime
