Square D HOM24L70S Load Center 70 Amp 120/240 VAC 2 Spaces NEMA 1

SCHNEIDER ELECTRIC
SKU: HOM24L70S
Availability: Out Of Stock
%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E
$43.07
$43.07
HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

The Square D HOM24L70S is a load center designed for residential and commercial use. This unit supports a maximum load of seventy amps at 120/240 volts. It features two spaces and four circuits with a NEMA 1 indoor enclosure. This load center is made for single-phase operations.

  • 70 amp current rating
  • 10 kA interrupt capacity
  • Supports wire sizes from 14 AWG to 4 AWG for copper or 12 AWG to 3 AWG for aluminum

Product Highlights

This model includes fixed main lugs and a surface cover. It meets UL certification standards and is suitable for indoor installations. The design allows for a full complement of compatible accessories and circuit breakers.

Product Information

Standard Information

  • Manufacturer: Square D
  • Warranty: Lifetime warranty available

Technical Specifications

  • Catalog Number: HOM24L70S
  • Voltage: 120/240 Volt
  • Current: 70 Amp
  • Number of Spaces: 2
  • Number of Circuits: 4
  • Enclosure: NEMA 1
  • Rated Operational Voltage: 120/240 V AC
  • Depth: 3.18 inches
  • Width: 4.80 inches
  • Height: 9.29 inches
  • Country of Origin: Mexico
  • UPC: 785901061168
