Square D HOM2150 Miniature Circuit Breaker 120/240V 150A

Product Description

The Square D HOM2150 is a miniature circuit breaker designed for 120/240 volts and rated for 150 amperes. This breaker is ideal for use in Homeline loadcenters and is compatible with wire sizes ranging from 4 AWG to 300 kcmil, whether using aluminum or copper.

• Voltage Rating: 120/240 VAC at 50/60 Hz
• Interrupting Rating: 10 kiloamperes
• Mounting Type: Plug-on for easy installation

Product Highlights

This miniature circuit breaker combines thermal magnetic operation with a common trip feature. It is suitable for residential and commercial applications, allowing for safe distribution of electrical power.

Product Information

Standard Information

• Manufacturer: Square D Co.
• Brand Name: Homeline

Technical Specifications

• UPC: 78590106583
• Wire Size: 4 AWG to 300 KCMIL (Aluminum/Copper)
• Approval: UL, CSA
• Number of Poles: 2
• Current Rating: 150 Amperes
• Terminal Type: Screw Clamp
• Catalog Number: HOM2150
• Type: Miniature, Thermal Magnetic, Common Trip
