Product Description
The Square D HOM115GFICP Homeline Miniature Circuit Breaker is engineered for fast installation and superior circuit protection. Designed to plug into Homeline load centers, it provides individual switching and tripping action. This single-pole breaker is UL listed and HACR rated, offering reliable performance for residential electrical systems.
- Fast installation
- Superior circuit protection
- Individual switching and tripping action
- UL listed
Product Highlights
Provides overload and short circuit protection, combined with Class A ground fault protection.
Product Information
Standard Information
-
Brand: Square D
-
Manufacturer Part Number: HOM115GFICP
-
Country of Origin: Mexico
Technical Specifications
-
Type: HOM
-
Brand: Square D
-
Depth: 2.98 Inch
-
Width: 1 in
-
Height: 3.13 Inch
-
Length: 2.98 Inch
-
Current: 15 Amp
-
Voltage: 120 Volt
-
Amperage: 15 Amp
-
Product UPC: 04756907109
-
12-Digit UPC: 047569071096
-
Applications: HACR rated
-
Mounting Type: Plug-In
-
TC Connection: Screw clamp terminals;AWG 14...AWG 10 aluminium/copper)1
-
Certifications: UL
-
Number of Poles: 1 Pole
-
Interrupt Rating: 10 kAIC
-
CA Prop65 Warning: WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
-
Country of Origin: Mexico
-
Line Rated Current: 15 A
-
Circuit Breaker Type: Ground Fault Protecting Class A 6 MA
-
Short Circuit Current: 10 kA
-
Current Rating: 15 Amps
-
Model: HOM115GFICP
-
Part Number: HOM115GFICP
-
Manufacturer: Square D by Schneider Electric
-
Item Type Name: Homeline Circuit Breaker 15 Amp Cd
-
Maximum Amperage (A): 15 A
-
Interruption Type: GFCI
-
Family: Homeline
-
Amp: 15
-
Volt: 120
-
Phase: 1
-
Category: Molded Case Circuit Breakers
-
Connection: Plug-In
-
Functions: LI - Long-Time and Instantaneous
-
Protection: Thermal Magnetic
-
AIC Ratings: 10kA@120V
-
Dimensions (HxWxD): 3.13 x 1 x 2.98
-
Power Capacity: 15-amp
