Square D HGL36025 Molded Case Circuit Breaker 25A 3 Pole

Product Description

The SQUARE D HGL36025 is a 3-pole molded case circuit breaker rated for 25 amps at 600 VAC and 250 VDC. It uses a thermal-magnetic trip mechanism to provide overload and short-circuit protection in panel-mounted electrical distribution applications. The breaker accepts wire sizes from 14 to 3/0 AWG via lug-style terminal connections, making it suitable for a wide range of conductor sizes found in commercial and industrial panels. Multiple breaking capacity ratings give this unit flexibility across demanding applications. At 4.19 pounds, the HGL36025 is a solid, durable device built for permanent installation by licensed electricians in service panels and switchgear enclosures.

The HGL36025 is designed for panel mount installation in commercial and industrial electrical distribution systems where 3-pole protection is required. It is a common choice for feeder and branch circuit protection in applications involving three-phase loads. The lug terminal connections and broad wire range of 14 to 3/0 AWG simplify field wiring for a variety of conductor sizes. Licensed electricians typically install this breaker in new construction, service upgrades, and replacement applications where a molded case design is specified.

Key Features

• Thermal-magnetic trip mechanism provides overload and short-circuit protection
• Rated 25 amps at 600 VAC and 250 VDC
• 3-pole configuration for three-phase circuit protection
• Lug terminal connections accept 14 to 3/0 AWG wire
• Multiple breaking capacity ratings for versatile application use
• Meets CE, CSA, IEC, and UL Listed standards

Compatibility

Designed as an OEM-style replacement molded case circuit breaker for panel-mount electrical distribution equipment requiring a 3-pole, 25-amp, 600 VAC device with lug terminals.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the panel before removing or installing any circuit breaker. Verify that conductor size and load calculations are consistent with the 25-amp rating and 14 to 3/0 AWG terminal range before terminating wires. Do not exceed the rated voltage or amperage for the circuit being protected.
