Square D HGA36125SA Circuit Breaker Pow 125A (3 Pole) REPLACEMENT MPN

Product Description

Square D HGA36125SA is a circuit breaker designed to protect electrical systems from overloads and short circuits. This model features thermal magnetic protection with a breaking capacity of eighteen kiloamperes at six hundred volts AC. The circuit breaker is equipped with dual-break rotating contacts that limit peak current during a short circuit event. It has a built-in push-to-trip button for manual operation. The PowerPacT H circuit breaker is available in both two-pole and three-pole designs, utilizing I-Line construction for easy installation in compatible applications.

• Breaking Capacity: 18kA at 600VAC
• Continuous Current Rating: 80% with ABC phase connection
• Includes factory-installed 120VAC shunt trip

Product Highlights

The PowerPacT H circuit breaker meets several standards including UL, CSA, NOM, and IEC, ensuring reliable performance in various applications.

Product Information

Standard Information

• Catalog Number: HGA36125SA
• Manufacturer: Schneider Electric

Technical Specifications

• Frame Type: G
• Voltage: 250 Volt
• Amperage: 125 Amp
• Number of Poles: 3 Pole
• Weight: 2.2 kg
• Dimensions: Width - 4.1 inches, Height - 4.5 inches, Depth - 86 mm
• Country of Origin: USA
• Warranty Length: 18 months
