Square D HDM36150 Circuit Breaker, Power, 150A, 3 Pole, 14kA

Product Description

Square D HDM36150 Circuit Breaker is designed to protect electrical systems from overload and short circuits. This model features thermal magnetic protection and has a breaking capacity of 14kA at 600VAC. The dual-break rotating contacts minimize peak current during faults. It includes a push-to-trip button for manual operation. Available in configurations with two and three poles, it is suited for various installation types including unit mount and I-Line constructions.

• 150 Amp, 3 Pole Configuration
• Thermal Magnetic Protection
• Breaking Capacity of 14kA at 600VAC

Product Highlights

This circuit breaker offers robust thermal protection with a continuous current rating of 80%. Compliant with UL, CSA, NOM, and IEC standards, it is CE marked for safety assurance.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Brand: Square D

Technical Specifications

• Catalog Number: HDM36150
• Voltage: 600VAC
• Frame Type: H
• Trip Type: Thermal Magnetic
• Number of Poles: 3
• Net Weight: 2.2 kg
• Application: Distribution
• Country of Origin: Canada
