Square D HDL36030AA Circuit Breaker, PowerPacT H, 30A, 3 Pole, 600VAC, 14kA

Product Description

Square D HDL36030AA is a circuit breaker designed to protect electrical systems from overloads and short circuits. This model belongs to the PowerPacT H-Frame series, offering thermal magnetic protection. Its breaking capacity is rated at fourteen kiloamperes at six hundred volts alternating current.

• Has dual-break rotating contacts to reduce peak current.
• Includes an integral push-to-trip button for manual tripping.
• Complies with UL, CSA, NOM, IEC standards, and is CE marked.

Product Highlights

This circuit breaker is suitable for distribution applications with a continuous current rating set at eighty percent. It is equipped with lugs for connection on both line and load sides, allowing for flexible installations.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: HDL36030AA
• Number of Poles: 3
• Breaking Capacity: 14kA at 600VAC
• Continuous Current Rating: 80%
• Application: Distribution
• Connection Type: Lugs, line; lugs, load; AWG 14...AWG 3/0 aluminum/copper terminal
• Warranty: Contractual Warranty: 18 months
• Country of Origin: United States
