Square D HDL26060 Molded Case Circuit Breaker 60A 2 Pole

Product Description

The SQUARE D HDL26060 is a 2-pole molded case circuit breaker rated at 60 amps, 600 VAC, and 250 VDC. It uses a thermal-magnetic tripping mechanism to provide overload and short-circuit protection in panel-mounted electrical distribution systems. Lug-style terminal connections accept wire sizes from 14 AWG to 3/0 AWG, giving installers flexibility across a range of conductor sizes. Licensed electricians install this breaker in commercial and industrial panelboards where multiple breaking capacity ratings and broad certification coverage are required. At 3.07 pounds, it is a standard-weight unit for its frame class.

The HDL26060 is suited for commercial and light industrial electrical distribution applications where a panel-mount, 2-pole breaker is needed at 60 amps. It fits branch and feeder circuit positions in load centers and distribution panels operating at up to 600 VAC. The thermal-magnetic trip mechanism responds to both sustained overloads and instantaneous fault currents, making it appropriate for motor branch circuits, HVAC equipment feeders, and general-purpose branch circuits in commercial construction and retrofit projects.

Key Features

• 60-amp continuous rating with thermal-magnetic trip for overload and short-circuit protection
• Dual voltage rating: 600 VAC and 250 VDC for versatile system applications
• 2-pole configuration for single-phase 240-volt or DC branch and feeder circuits
• Lug terminal connections accept 14 AWG to 3/0 AWG conductors
• Panel-mount design for standard distribution board installation
• Multiple breaking capacity ratings for use across varied fault-current environments
• Certified to CE, CSA, IEC, and UL standards

Compatibility

Designed as an OEM-style replacement molded case circuit breaker for commercial and industrial panelboards requiring a 2-pole, 60-amp, 600 VAC panel-mount breaker in the HDL frame class.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the panel before installing or replacing this breaker. Confirm that conductor sizing, torque requirements, and panel bus compatibility comply with the manufacturer instructions and NEC Article 240. Do not exceed the breaker's voltage or amperage ratings for the intended circuit.
