Square D HDL26035 Molded Case Circuit Breaker 35A 2P

Product Description

The SQUARE D HDL26035 is a 2-pole, molded case circuit breaker rated for 35 amps, 600 VAC, and 250 VDC. It uses a thermal-magnetic trip mechanism that responds to both sustained overloads and short-circuit faults, providing dual-mode overcurrent protection. Lug-style terminal connections accept 14 AWG through 3/0 AWG conductors, making it suitable for a wide range of feeder and branch circuit applications. The panel mount configuration fits standard industrial and commercial enclosures. Electricians and electrical contractors install this breaker in distribution panels, motor control centers, and industrial power systems where dependable overcurrent protection is required.

This circuit breaker is suited for commercial and industrial panel installations requiring 2-pole overcurrent protection at voltages up to 600 VAC or 250 VDC. Its multiple breaking capacity ratings make it applicable across a range of fault-current environments. The thermal-magnetic trip design provides reliable response to both slow-developing overloads and instantaneous short circuits, which is a common requirement in motor feeder, HVAC equipment, and general-purpose branch circuit applications.

Key Features

• 35-amp continuous current rating with thermal-magnetic trip for overload and short-circuit protection
• Rated 600 VAC and 250 VDC for broad application flexibility
• 2-pole configuration for single-phase 240-volt or DC circuit protection
• Lug terminal connections accept 14 AWG to 3/0 AWG conductors
• Multiple breaking capacity ratings suit varied fault-current environments
• Panel mount design fits standard industrial and commercial enclosures

Compatibility

Designed as an OEM-style replacement molded case circuit breaker for commercial and industrial panel and enclosure applications requiring a 2-pole, 35-amp, 600 VAC thermal-magnetic breaker with lug terminals.

Installation Notes

Installation must be performed by a licensed electrician in accordance with NFPA 70 (NEC) and all applicable local codes. De-energize and lock out the panel before removing or installing the breaker. Verify conductor sizing matches the lug terminal range of 14 AWG to 3/0 AWG and that torque is applied per the panel or enclosure manufacturer specifications. Do not install in circuits exceeding the rated voltage or amperage of this device.
