Square D HDL26015 Molded Case Circuit Breaker 15A 2P

Product Description

The SQUARE D HDL26015 is a 2-pole, molded case circuit breaker rated for 15 amps at 600 VAC and 250 VDC. It uses a thermal-magnetic tripping mechanism to provide overcurrent and short-circuit protection in industrial and commercial panel applications. Lug-style terminal connections accept wire sizes from 14 AWG through 3/0 AWG, giving installers flexibility across a wide range of conductor sizes. The HDL26015 is panel-mount style and carries multiple breaking capacity ratings, making it suitable for varied fault-current environments. Licensed electricians and industrial maintenance technicians are the primary installers for this device.

This circuit breaker is designed for use in molded case circuit breaker panels in commercial and industrial electrical distribution systems. It is well suited for branch circuit and feeder protection where a 2-pole, 15-amp device at 600 VAC is required. The dual-voltage rating supports both AC and DC distribution panel configurations. Its compact panel-mount form factor allows straightforward integration into existing or new switchboard and panelboard assemblies.

Key Features

• 15-amp continuous current rating with thermal-magnetic trip mechanism for reliable overcurrent protection
• Dual voltage rating: 600 VAC and 250 VDC
• 2-pole configuration for multi-wire branch circuit protection
• Lug terminal connections compatible with 14 AWG to 3/0 AWG conductors
• Multiple breaking capacity ratings for use in varied fault-current installations
• Panel-mount design for integration into standard molded case circuit breaker enclosures
• Certified to CE, CSA, IEC, and UL Listed standards

Compatibility

Designed as an OEM-style replacement or new-installation molded case circuit breaker for commercial and industrial panelboards requiring a 2-pole, 15-amp, 600 VAC panel-mount breaker.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the panel before installing or replacing this breaker. Verify that conductor sizing and terminal torque specifications comply with the breaker manufacturer documentation and NEC Article 240. Do not exceed the breaker amperage or voltage ratings for the circuit being protected.
