Square D HDA36015 Molded Case Circuit Breaker 15A 600V 3P

Product Description

The SQUARE D HDA36015 is a 3-pole, plug-in molded case circuit breaker rated for 15 amps at 600 VAC. It uses a thermal-magnetic trip mechanism to provide both overload and short-circuit protection in a single device. The breaker accepts I-Line and lug terminal connections, giving installers flexibility in panel configurations. It is designed for use in commercial and industrial power distribution systems where reliable branch-circuit protection is required. Licensed electricians typically specify this breaker for feeder and branch circuit applications in load centers and switchboards that accept SQUARE D I-Line mounting.

The HDA36015 is suited for commercial and light industrial electrical distribution panels operating at up to 600 VAC. It handles wire sizes from 14 AWG through 3/0 AWG, covering a broad range of conductor sizes used in branch and feeder circuits. This breaker fits panelboards and switchboards designed to accept plug-in or I-Line style molded case circuit breakers. Installers working on multi-phase commercial systems will find the 3-pole configuration appropriate for 208V, 240V, 480V, and 600V three-phase applications.

Key Features

• Thermal-magnetic trip mechanism provides both overload and short-circuit protection
• 3-pole configuration for three-phase branch and feeder circuit protection
• Rated 15 amps at 600 VAC for broad voltage system compatibility
• Accepts I-Line plug-in and lug terminal connections for flexible installation
• Wire range of 14 AWG to 3/0 AWG accommodates a wide variety of conductor sizes
• Multiple breaking capacity ratings for varied fault-current environments

Compatibility

Designed as an OEM-style replacement molded case circuit breaker for SQUARE D I-Line and lug-compatible panelboards and switchboards rated for plug-in style breaker installation.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the panel before removing or installing the breaker. Verify that the panelboard bus accepts I-Line plug-in style breakers before seating the device. Confirm conductor sizing and torque requirements per the panel manufacturer specifications and NEC Article 240.
