Square D H367NR Heavy Duty Safety Switch 800 Amp 4-Pole Replacement MPN

Product Description

The Square D H367NR is a heavy duty safety switch designed for use in demanding environments. This fusible disconnect switch operates at a maximum of 800 amps and features a 600 volt AC/DC rating. It complies with UL standards and holds a NEMA 3R rating for outdoor installations. The switch has three poles and a neutral that is factory installed. Its robust construction includes galvannealed steel, ensuring durability in various conditions.

• 800 Amp capacity
• NEMA 3R rating for outdoor use
• UL listed for safety

Product Highlights

This heavy duty safety switch is equipped with a quick-make, quick-break mechanism for fast response. It also includes a dual cover interlock and an easy-to-read color-coded handle, making operation straightforward. The switch accepts H, J, K, L, and R fuse types and is ideal for surface mounting, providing flexibility in installation.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: H367NR
• Rated Current: 800 Amps
• Voltage Rating: 600 Volts AC/DC
• Number of Poles: 3
• Enclosure Rating: NEMA 3R
• Weight: 382.94 lbs
• Dimensions: 17.75 inches (depth) x 36.62 inches (width) x 69.13 inches (height)
• Country of Origin: Mexico
• Warranty: 18 months
