Square D EGB24030 Circuit Breaker 30A 480V 2 Pole

Product Description

The SQUARE D EGB24030 is a 2-pole miniature circuit breaker rated for 30 amps at 480Y/277 volts, designed for bolt-on panel installation. It delivers a 35 kA interrupting capacity, making it suitable for commercial and industrial distribution panels where high fault-current ratings are required. The lug terminal connection type accepts 12 and 14 AWG conductors. This breaker provides overcurrent and short-circuit protection for branch circuits and is installed by licensed electricians working on low-voltage distribution systems.

The EGB24030 is intended for use in commercial and light industrial electrical distribution panels operating at 480Y/277 volts. Typical applications include branch circuit protection in multi-story buildings, manufacturing facilities, and other settings where a bolt-on breaker in a matching loadcenter or panelboard is required. The 2-pole configuration handles two-phase branch circuits in a 480Y/277-volt system.

Key Features

• 30-amp overcurrent rating with 35 kA interrupting capacity
• Rated for 480Y/277-volt systems, 2-pole configuration
• Bolt-on mounting for secure panel installation
• Lug terminal connection compatible with 12 and 14 AWG wire
• Compact miniature circuit breaker form factor

Compatibility

Designed as an OEM-style replacement miniature circuit breaker for bolt-on loadcenters and panelboards rated at 480Y/277 volts accepting 2-pole breakers of this frame size.

Installation Notes

Installation must be performed by a qualified, licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the panelboard before removing or installing any circuit breaker. Verify that the panel busbar accepts bolt-on breakers and that the breaker ampacity and voltage rating match the circuit requirements before installation.
