Description

Product Description

The Square D EDB34035 is an E-Frame breaker designed for lighting panelboards, offering reliable performance. This 3-pole, bolt-on circuit breaker is rated at 35A and 480Y/277 VAC. It provides overload and short circuit protection with a thermal-magnetic trip unit and trip indicator. It is HID and HACR rated and calibrated for 40 degrees C.

  • Superior overload and short circuit protection
  • Thermal-magnetic trip unit with signal indicator
  • HID and HACR rated

Product Highlights

Provides reliable circuit protection for lighting panelboards with thermal-magnetic trip functionality.

Product Information

Standard Information

  • Brand: SQUARE D
  • Manufacturer Part Number: EDB34035
  • Country of Origin: Mexico
Technical Specifications
Type
Branch
Brand
Square D
Depth
4.05 Inch
Frame
E-FRAME
Width
2.94 in
Height
5.66 Inch
Length
4.05 Inch
Voltage Rating
120/240/277 VAC at 50/60 Hz, 480 VAC Star/277 VAC at 50/60 Hz (UL/CSA), 240 VAC at 50/60 Hz (IEC)
Amperage
35 Amp
Sub Brand
EDB
Trip Type
Thermal-magnetic
Module Type
E-Frame
Applications
HID rated;HACR rated
Mounting Type
Bolt-On
TC Connection
LUGS #12 TO #2/0 AWG(AL) - #14 TO #2/0 AWG(CU)
Certifications
CULus
Number of Poles
3 Pole
Interrupt Rating
18 kAIC
Line Rated Current
35 A
Catalog Number
EDB34035
Manufacturer
Schneider Electric
UPC
785901875277
GTIN
00785901875277
Poles
3
Rating
HID, HACR
Calibration Temperature
40 degrees C
Voltage
277/480Y VAC
Interrupting Rating
25 Kiloampere at 120/240 VAC, 18 Kiloampere at 480 VAC Star/277 VAC or 277 VAC (UL/CSA)
Application
Lighting
Used On
Class 515 NF Series Panelboard
Approval
UL, CSA, NOM 117
Frame Type
E
Size
2.94 Inch W x 4.05 Inch D x 5.66 Inch H
Tripping Method
Thermal Magnetic
Terminal Wire Size
12 to 2/0 AWG (Aluminum), 14 to 2/0 AWG (Copper)
Range Of Product
125 A Frame EDB-EGB-EJB
Product Or Component Type
miniature circuit-breaker
Device Short Name
EDB
Tightening Torque
3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
Breaking Capacity Code
D
Product Destination
NF panelboard
Electrical Connection
lugs aluminium
Number Of Spaces Required
3
Circuit Breaker Application
HID rated || HACR rated
Mounting Mode
bolt-on
Protection Type
short-circuit || overload
Local Signalling
trip indicator
Awg Gauge
AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
Breaking Capacity
18 kA 277 V AC || 25 kA 240 V AC || 18 kA 480Y/277 V AC || 25 kA 120 V AC || 25 kA 120/240 V AC
Trip Unit Technology
thermal-magnetic
[Ue] Rated Operational Voltage
480Y/277 V AC
Product Certifications
cULus
Ambient Air Temperature For Operation
40 °C
ECCN
EAR99
UNSPSC
39121603
Standards
Trade Agreements Act (TAA)
AWG Range
AWG 12...AWG 2/0
Current Rating
35A
Rated Voltage
480Y/277V ac
Torque
3.9-3.9 N.m
Phase
3 ph
Connection
Lug Connection
Wire
12 to 2/14 to 2/0 AWG
Mounting
Bolt-On Mounting
Temperature
40 deg C
Frequency
50/60 Hz
