Square D EDB14015 Miniature Circuit Breaker 15 Amp 277 Volt

Product Description

The Square D EDB14015 is a sixteen amp miniature circuit breaker designed for efficient overload and short circuit protection in electrical systems. It is compatible with Square D NF Panelboards, ensuring reliability and performance.

• Rated for 15 Amps with a maximum operating voltage of 277 VAC.
• Trip type is thermal-magnetic with a trip current of 875 Amps.
• UL listed for Switching duty and High Intensity Discharge applications.

Product Highlights

This circuit breaker provides essential protection and is equipped with mounting bolts for stable installation. It features a hold current of 270 Amps and an interrupt rating of 25 kA at 120 VAC. This device is calibrated for a maximum operating temperature of forty degrees Celsius.

Product Information

Standard Information

• Catalog Number: EDB14015
• Manufacturer: Schneider Electric

Technical Specifications

• Type: Miniature circuit-breaker
• Voltage: 277 VAC
• Amperage: 15 Amp
• Frame: E-FRAME
• Dimensions: 4.05 inches (length) x 0.98 inches (width) x 5.66 inches (height)
• Weight: 2 lb
• Interrupt Rating: 25 kAIC
• Country of Origin: Mexico
• Warranty: 18 months
