Square D Co. HL100WNS2M26 Telemecanique Limit Switch

Product Description

Square D Co. HL100WNS2M26 is a durable limit switch designed for severe duty applications. This limit switch features a fixed sequence type operation with a two normally open contact arrangement. The product's connection type is a half inch NPT conduit, suitable for metric thread. The switch operates in both clockwise and counterclockwise directions and utilizes a spring return mechanism resulting in snap action.

• Severe Duty, Extra Heavy Duty rating
• Operating temperature range from zero to three hundred fifty degrees Fahrenheit
• Mechanical force of one hundred seventy ounce-inches

Product Highlights

This limit switch can be utilized in a variety of industrial applications where reliable operation is required. Ideal for motor control systems and heavy machinery.

Product Information

Standard Information

• Manufacturer: Square D Co.
• Brand: Square D Co.

Technical Specifications

• UPC: 78590115107
• Contact Configuration: 2NO
• Operating Force: 170 oz-Inch
• Total Travel: 70 Deg
• Pretravel: 9 Deg
• Differential Travel: 6 Deg
• Connection Type: 1/2 Inch NPT Conduit (Metric Thread)
• Operating Temperature: 0 to 350 Deg F
• Body Material: Cast Aluminum
• Enclosure Type: NEMA 1/4/13, IP65, IP66
• Approvals: UL, CSA
• Catalog Number: HL100WNS2M26
