Square D Co. 9007MS01S0200 Telemecanique Limit Switch 240Vac 10Amp Ms +Options

Product Description

The Square D Co. 9007MS01S0200 is a Telemecanique limit switch designed for use in various control applications. This device operates at 240 VAC with a contact rating of 10 Amperes and is suitable for machine tools, earth moving equipment, and general transportation. Its compact and rugged design, featuring epoxy encapsulation, ensures reliable performance in demanding environments.

• Compact design with heavy-duty construction
• SPDT contact configuration: 1NO-1NC
• Rated for 240 VAC at 10 Amperes

Product Highlights

This limit switch features a snap action operation type that provides fast response times in automation tasks.

Product Information

Standard Information

• Manufacturer: Square D Co.
• Brand: Square D Co.

Technical Specifications

• UPC: 78590155053
• Total Travel: 0.19 Inch
• Pretravel: 0.07 Inch
• Differential Travel: 0.004 Inch
• Contact Rating: 240 VAC 10 Ampere, 28 VDC 5 Ampere
• Connection Type: 18 AWG 6 Ft Yellow SJTO Pre-Wired Cable
• Operating Temperature: -4 to 220 Deg F
• Body Material: Rugged Die-Cast Zinc
• Enclosure: NEMA 1/2/4/6/6P/12/13, IP67
• Approval: UL, CSA, CE
• Application: Machine Tool, Earth Moving Equipment, General Transportation
