Square D Co. 9007AO1 Telemecanique Snap Switch 600Vac 15Amp Ao +Options

Product Description

Square D Co. 9007AO1 is a Telemecanique Snap Switch designed for heavy-duty applications. This switch operates at six hundred volts AC and fifteen amps. It includes options to customize its use in industrial settings.

• Heavy Duty, Industrial Type
• SPDT Configuration with 1NO-1NC Contacts
• Cast Zinc Body Material for Durability

Product Highlights

This snap switch is suitable for a variety of motor control applications. It features a reliable spring return and snap action operation to ensure effective performance in tough environments.

Product Information

Standard Information

• Manufacturer: Square D Co.
• UPC: 78590175903

Technical Specifications

• Contact Rating: 600 VAC/VDC 15 Ampere
• Contact Configuration: SPDT, 1NO-1NC Double Break
• Connection Type: Screw Clamp Terminal
• Operating Temperature: -20 to 185 Deg F
• Body Material: Cast Zinc
• Operating Force: 7 to 11 Oz
• Total Travel: 0.103 to 0.125 Inch
• Pretravel: 0.057 to 0.074 Inch
• Differential Travel: 0.015 to 0.025 Inch
• Actuator/Head Type: Plunger Head
