Square D CH225 2-pole Circuit Breaker 25 Amp 120/240V

Product Description

The SQUARE D CH225 is a 2-pole, plug-on circuit breaker rated for 25 amps at 120/240 volts AC, designed for use in residential and light commercial load centers. It provides overcurrent protection with a 10 kiloamp interrupting rating, making it suitable for branch circuit applications where reliable fault protection is required. The plug-on mounting design allows for direct installation into compatible load centers without additional hardware. Licensed electricians install this breaker as part of panel upgrades, new construction wiring, or branch circuit additions.

This breaker is intended for load center installations in residential and light commercial settings. It handles branch circuits supplying 240-volt loads such as appliances, HVAC equipment, and subpanels, as well as 120-volt circuits when used in a tandem configuration. It accepts wire sizes from 14 to 8 AWG for standard applications and 14 to 10 AWG depending on configuration, accommodating a range of conductor sizes common in residential branch wiring.

Key Features

• 25-amp current rating for standard branch circuit protection
• 2-pole design supports 120/240 volt AC circuits
• 10 kiloamp interrupting rating for fault current protection
• Plug-on mounting for fast, tool-free installation into compatible load centers
• Accepts 14 to 8 AWG wire for flexible conductor sizing

Compatibility

Designed as an OEM-style plug-on replacement breaker for compatible residential and light commercial load center panels accepting the CH-series form factor.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. The main breaker or utility disconnect must be shut off and the panel confirmed de-energized before installing or removing any circuit breaker. Verify that conductor size and insulation rating match the circuit requirements before terminating wires. Do not exceed the maximum wire size rating for the breaker terminals.

Technical Specifications

• Current Rating: 25 amps
• Voltage Rating: 120/240 volts AC
• Number of Poles: 2
• Interrupting Rating: 10 kiloamps
• Mounting Type: Plug-On
• Wire Size: 14 to 8 AWG / 14 to 10 AWG
• Used On: Load Center

Standard Information

• Brand: SQUARE D
• Manufacturer Part Number: CH225
