Square D ATV12H075F1 AC Drive 1 Hp 115V In 230V Out

Product Description

Square D ATV12H075F1 is an AC drive with a power rating of 1 horsepower. It accepts an input voltage of 115 volts and provides an output of 230 volts. This drive is designed for controlling motor speed and efficiency.

• Input Voltage: 100 to 120 Volt AC at 50/60 Hertz
• Output Voltage: 200 to 240 Volt AC at 50/60 Hertz
• Enclosure Type: IP20

Product Highlights

This drive is suitable for use in various applications requiring variable speed control. It is ideally suited for HVAC systems and industrial equipment.

Product Information

Standard Information

• Manufacturer: Square D Co.
• Type: AC

Technical Specifications

• Size: 4.13 Inch Width x 6.15 Inch Depth x 5.59 Inch Height
• Input Current: 18.9 Amp at 100 Volt AC, 15.7 Amp at 120 Volt AC
• Approval: UL, CSA, CE, C-TICK, GOST, NOM
• Constant Torque HP: 1
• Constant Torque kW: 0.75
• Transient Current: 6.3 Ampere
• Drive Type: Adjustable Frequency
