Square D A9.85 Thermal Unit Power Class 20

Product Description

The Square D A9.85 Thermal Unit is designed to provide protection for motors, controllers, and branch circuit conductors from overheating caused by prolonged motor overcurrents, including locked rotor situations. This unit trips in twenty seconds or less during overload conditions, ensuring timely protection. The construction is one-piece, facilitating a direct heat transfer as the motor current passes through a heater winding within the unit. If an overload occurs, a special solder melts, allowing a ratchet wheel to disengage, which then opens the control circuit contacts and motor contacts.

• Melting alloy thermal units available in multiple designs: standard trip (Class 20), slow trip (Class 30), quick trip (Class 10)
• Capable of responding to overload conditions
• Manual reset required after cooling

Product Highlights

This thermal unit is built for reliable overload protection for a wide range of motors and conforms to Class 20 standards.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Brand: Square D

Technical Specifications

• Catalog Number: A9.85
• Trip Type: Standard Trip - Class 20
• Country of Origin: Mexico
• Warranty Length: 18 months
• GTIN: 00785901585428
• UPC: 785901585428
• Applications: For use in melting alloy thermal overload relays
