Square D 9998DA2V14 Contactor Replacement Coil

Product Description

The SQUARE D 9998DA2V14 is a replacement contactor coil designed for use with the 4 pole 8910DPA contactor series. The coil is the electromagnetic core of contactor operation — when energized, it pulls in the armature and closes the load contacts, switching the circuit. Replacing a failed or damaged coil restores full contactor function without requiring replacement of the entire contactor assembly. This part measures 3.7 inches in length, 2.6 inches in width, and 1.7 inches in height, and weighs 0.16 pounds. Licensed electricians and HVAC technicians working on commercial or industrial control panels are the primary installers of this component.

This coil is suited for applications where the 4 pole 8910DPA contactor is already installed and the coil has failed due to overheating, voltage surge, or general wear. Common install scenarios include motor control centers, HVAC compressor banks, lighting contactors, and other multi-pole switching applications where the contactor body remains serviceable and only the coil needs replacement. Replacing the coil rather than the full contactor reduces material cost and downtime on the job.

Key Features

• Direct replacement coil for the 4 pole 8910DPA contactor series
• Restores contactor function without full assembly replacement
• Compact form factor: 3.7 inches x 2.6 inches x 1.7 inches
• Lightweight at 0.16 pounds for easy handling during panel service
• Sold individually — one coil per package

Compatibility

Designed for use with the SQUARE D 4 pole 8910DPA contactor series as a direct coil replacement.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the NEC and applicable local codes. De-energize and lock out the circuit at the panel before removing the existing coil or handling any contactor components. Verify the replacement coil voltage rating matches the control circuit voltage before installation. Do not attempt coil replacement with the contactor under load or energized.
