Square D 9421LC43 NEMA Operating Mechanism Handle

Product Description

The Square D 9421LC43 is a handle assembly designed for circuit breaker mechanisms. This assembly features a robust all-metal construction. It is compatible with both 2 and 3 pole PowerPact B circuit breakers with a 125A frame and PowerPacT H and J circuit breakers with a 250A frame. The handle mechanism includes a three-inch chrome plated handle.

• Compatible with various PowerPact and PowerPacT circuit breakers
• Can be padlocked in the Off position
• Rated for NEMA Type 1, 3R, 4, 4X, and 12 enclosures

Product Highlights

This assembly allows secure operation and isolation of circuit breakers. It can be locked off with up to three padlocks to enhance safety when the enclosure door is open.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• MPN: 9421LC43
• Handle Length: 3 inches
• Enclosure Type: NEMA 1/3R/4/4X/12
• Warranty Length: 18 months
• Country of Origin: Mexico
• UPC: 785901037040
• GTIN: 00785901037040
• Trip Type: Automatic
