Square D 9080gcb50 Circuit Protector 250 Volt 5 Amp Type Nema

Product Description

The Square D 9080GCB50 Linergy thermal magnetic circuit protector is a trip-free device mountable on a 35 mm DIN track or Square D terminal block track. It has a current rating of 5.0 Amperes. The thermal feature trips on overloads of ten times the rated current or less, and the magnetic mechanism trips instantaneously on short circuits. Maximum rating of 200 A, not exceeding 10,000% rated current.

• Current ratings from 0.1 to 15 A
• Trip-free design
• DIN track mountable

Product Highlights

This thermal magnetic circuit protector is suitable for industrial applications and provides reliable circuit protection with both thermal and magnetic trip mechanisms.

Product Information

Standard Information

• Brand: SQUARE D
• Manufacturer Part Number: 9080GCB50
• Country of Origin: Germany

Technical Specifications

• Type: Circuit Protector
• Brand: Square D
• Voltage: 250 Volt
• Amperage: 5 Amp
• Standard: CSA C22.2 No 235,DIN 57470,UL 1077
• Wire Size: AWG 16...AWG 10 copper
• Applications: Industrial Application
• Strip Length: 0.5 in
• TC Connection: Box lugs
• Certifications: CE,CSA File 025490 Class 3211 07,UL Recognized E233026 CCN QVNU2
• Conductor Size: 16-10 AWG
• Number of Poles: 1 Pole
• Line Rated Current: 5 A
• Operating Temperature: -22 to 140 degrees F (-30 to 60 degrees C)
• Size: 0.5 in
• Depth: 0.5 in
• Width: 3.15 in
• Height: 3.45 Inch
• Length: 0.5 in
• Manufacturer: Schneider Electric
• Country of Origin: Germany
• Made in USA: No
• Current: 5 A
• Voltage Rating: 250 VAC, 65 VDC
• Features: Mercury Free
• Trip Type: Trip-Free, Thermal Magnetic
• For Use With: 35mm/GH
• Housing Color: Black
• Overall Depth: 3.15 in
• Overall Width: 0.5 in
• Max. Wire Size: 10 AWG
• Min. Wire Size: 16 AWG
• Overall Length: 3.11 in
• Connection Type: Track Mount
• Maximum Voltage: 250 V AC
• Number of Tiers: 1
• Wire Size Ranges: 16 AWG - 10 AWG
• AC Voltage Rating: 250VAC
• DC Voltage Rating: 65VDC
• Terminal Connection: Box Lugs
• For Maximum Wire Size: 10 AWG
• For Minimum Wire Size: 16 AWG
• For Conductor Material: Copper
• Circuit Protection Type: Circuit Breaker
• Mounting: 35 MM DIN Rail
• Approval: UL 1077, CSA, CE
• Series: 9080GCB
• Amperage Rating: 5 A
• Mounting Type: DIN Rail/Track
• Temperature Rating: -4 to 140 deg F
• Connection: Box lugs
• Special Features: Thermal-magnetic;Overcurrent
• Contact Operation: Trip-free
• Poles Description: 1 P
• Tightening Torque: Control circuit 7-7 lbf.in cage type connector
• Wire Stripping Length: 0.5 in
• Temperature For Tripping: 70 F
• Rated Operational Voltage: 250 V AC;65 V DC
• Line Rated Current - Metric: 5 A
• Ambient Air Temperature For Op: -162 F
• Wiring Device Additional Infor: Factory wiring only
