Square D 9080FB3611CC Fuse Holder 30A 600V 3 Pole Cc Class

Product Description

The SQUARE D 9080FB3611CC is a 3-pole, surface mount fuse holder rated for 30 amps and 600 volts, designed to accept Class CC fuses. It provides a compact, panel-ready means of fuse protection in industrial and commercial control circuits. The holder mounts directly to a surface, making installation straightforward in enclosures, control panels, and distribution assemblies. At 0.24 pounds and measuring 3.1 inches in length, 2.4 inches in width, and 1.3 inches in height, it fits in tight cabinet layouts without sacrificing accessibility. Electricians and panel builders specify this unit where reliable Class CC fuse coordination is required alongside a clean surface-mount footprint.

This fuse holder is suited for use in industrial control panels, machine tool wiring, and commercial electrical distribution assemblies where branch circuit or control circuit overcurrent protection is needed. The 3-pole configuration handles three-phase or multi-circuit applications in a single, consolidated block. It is commonly installed by licensed electricians and panel builders working on motor control centers, automation panels, and similar equipment requiring Class CC fuse compatibility at 600 volt ratings.

Key Features

• Rated 30 amps and 600 volts for robust overcurrent protection in control and power circuits
• 3-pole design consolidates three fuse positions into a single surface-mount block
• Compatible with Class CC fuses, providing high-rejection fuse coordination
• Surface mount configuration simplifies installation in enclosures and control panels
• Compact footprint: 3.1 inches long, 2.4 inches wide, 1.3 inches tall
• Lightweight at 0.24 pounds, reducing load on panel mounting surfaces

Compatibility

Designed for use with Class CC fuses. Intended as a surface-mount fuse holder for industrial and commercial control panel applications requiring a 3-pole, 30-amp, 600-volt fuse block.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lock out all circuits before mounting or servicing the fuse holder. Verify that replacement fuses match the Class CC designation and the circuit ampere rating before inserting. Do not exceed the 30-amp or 600-volt ratings of the holder under any operating condition.
