Square D 9050JCK70V24 Time Delay Relay Dpdt 240V

Product Description

The SQUARE D 9050JCK70V24 is a multi-function time delay relay designed for industrial and commercial control applications. It operates at 240 volts AC and provides a maximum delay range of 999 minutes, with a minimum delay of 0.05 seconds, giving technicians precise timing control across a wide range of system configurations. The relay uses a DPDT (double-pole, double-throw) contact configuration rated at 10 amps. Five selectable timer functions are built into a single unit, making it a versatile choice for electricians and controls technicians who need one relay to cover multiple timing scenarios.

This relay is suited for use in motor control centers, automated process equipment, HVAC control panels, and other industrial or commercial electrical systems where timed switching is required. Its broad delay range from under one second to 999 minutes covers both quick-cycle and long-duration timing applications. Installation is typically performed by licensed electricians or industrial controls technicians working on low-voltage control circuits.

Key Features

• Five timer functions: Delay On Break, Delay On Make, Interval, Repeat Cycle, and Single Shot
• Maximum delay range of 999 minutes with a minimum delay of 0.05 seconds
• DPDT contact configuration rated at 10 amps
• 240 volt AC coil voltage for direct integration into standard control circuits
• Compact footprint at 4.3 inches long, 1.9 inches wide, and 2.6 inches tall

Compatibility

Designed as an OEM-style replacement or direct-install time delay relay for industrial and commercial control panel applications requiring a DPDT, multi-function timing relay at 240 volts AC.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the NEC and applicable local codes. De-energize and lock out the control panel before removing or installing the relay. Verify coil voltage and contact ratings match the circuit requirements before wiring. Do not exceed the 10-amp contact rating.
