Square D 9013FRG22J23 Pressure Switch, DPST, 4 to 45 psi

Product Description

The Square D 9013FRG22J23 is a pressure switch designed for reliable operation in industrial settings. It features a single 1/4 inch FNPS port with a reverse action for effective control. The factory setting ensures operation at 40/20 psi, and it provides a differential range of 6 to 20 psi, making it suitable for various applications such as water pumps.

• Compatible with 1 hp motors at both 120V and 240V.
• Durable construction supports a temperature range from -22 degrees to 257 degrees Fahrenheit.
• DPST electrical contact form offers enhanced reliability.

Product Highlights

This pressure switch is designed for water pump applications and features key specifications that support efficient operation in demanding commercial environments.

Product Information

Standard Information

• Manufacturer: Schneider Electric (Square D)
• Part Number: 9013FRG22J23

Technical Specifications

• Pressure Switch Action: Reverse
• Electrical Contact Form: DPST
• Factory On/Off Setting: 40/20 psi
• Pressure Switch Range: 4 to 45 psi
• Maximum Operating Temperature: 257 degrees Fahrenheit
• NEMA Rating: 1
• HP @ 1 Phase - 120V: 1 hp
• HP @ 1 Phase - 240V: 1 hp
• HP @ 3 Phase - 240V: 1 hp
• Operating Temperature Range: -22 degrees to 257 degrees Fahrenheit
