Square D 9007R Limit Switch Head 7.6 in for 9007C

Product Description

The SQUARE D 9007R is a limit switch head designed as a replacement accessory for use with the 9007C limit switch body. Limit switch heads mount to the actuator body and contain the mechanical linkage or roller mechanism that initiates the switching action when contacted by moving machinery, doors, or equipment. This part measures 7.6 inches in overall length and weighs 0.1 pounds, making it a compact, direct-replacement component. It is typically installed by licensed electricians or industrial maintenance technicians in control panel, conveyor, and machinery guard applications where precise positional switching is required.

The 9007R limit switch head is suited for industrial and commercial control circuit applications where the existing 9007C body requires a new or replacement head. Typical install scenarios include conveyor end-of-travel detection, machine guarding interlocks, and equipment door position sensing. This head ships as a single unit and is intended for use in new assembly or field replacement on existing 9007C-series installations.

Key Features

• Direct replacement limit switch head for the 9007C series actuator body
• Overall length of 7.6 inches for compatibility with standard 9007C mounting configurations
• Lightweight at 0.1 pounds for easy field handling and installation
• Sold as a single unit, matching original equipment form and function

Compatibility

Designed for use with the SQUARE D 9007C limit switch body as stated by the manufacturer.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NFPA 70 (NEC) requirements. Disconnect and lock out all power to the control circuit before removing or installing the limit switch head. Verify that the replacement head is fully seated and secured to the 9007C body before restoring power. Do not force the actuator mechanism beyond its rated travel range during installation.
