Square D 9007MS07S0100 Limit Switch Spdt Nc Roller Plunger

Product Description

The SQUARE D 9007MS07S0100 is a general-purpose limit switch designed for industrial and commercial control applications. It features a single-pole double-throw (SPDT) contact form with a normally closed (NC) configuration and a parallel roller plunger actuator mounted at the top of the metal body. The switch ships prewired for straightforward installation and carries an IP67 ingress protection rating, making it suitable for wet and dusty environments. It operates across a wide temperature range of -40 degrees F to 220 degrees F and is rated for NEMA 1, 2, 4, 6, and 6P enclosure classifications. Electricians and control technicians install this switch in automated machinery, conveyor systems, and process equipment where position sensing or travel-limit detection is required.

This limit switch is suited for both light industrial and heavy-duty commercial control panel applications. The bushing mount style allows secure panel or bracket installation in tight machine frames. The prewired terminal configuration reduces field termination time and supports clean wiring runs inside control enclosures. Its NEMA 6P and IP67 ratings make it a practical choice for washdown areas, outdoor installations, and environments with exposure to coolants or process fluids.

Key Features

• SPDT contact form with normally closed (NC) configuration for reliable position detection
• Parallel roller plunger actuator with top-mount location for direct mechanical actuation
• IP67 ingress protection rating suitable for washdown and submersion-rated environments
• NEMA 1, 2, 4, 6, and 6P ratings covering indoor, outdoor, and watertight applications
• Metal body construction for durability in industrial settings
• Prewired terminals for faster field installation and reduced wiring errors
• Wide operating temperature range: -40 degrees F to 220 degrees F

Compatibility

Designed as an OEM-style replacement or direct installation limit switch for industrial control systems requiring a SPDT NC parallel roller plunger actuator with top bushing mount and prewired output in NEMA 4, 6, or 6P rated enclosures.

Installation Notes

Installation is typically performed by a licensed electrician or qualified control technician in accordance with NEC requirements and applicable local codes. De-energize and lock out the machine control circuit before mounting or wiring this switch. Secure the bushing mount with appropriate hardware to prevent movement under repeated actuation. Verify actuator alignment and travel force does not exceed the 80-ounce maximum operating force specification provided in the input data.
