Square D 9007MS02S0084 Limit Switch Spdt Nc Roller Plunger

Product Description

The SQUARE D 9007MS02S0084 is a general-purpose industrial limit switch designed for reliable position sensing in automated machinery and control systems. It features a single-pole double-throw (SPDT) contact form with a normally closed (NC) configuration and a parallel roller plunger actuator mounted at the top of the unit. The metal body construction and IP67 ingress protection rating make it suitable for demanding environments where moisture and debris are present. The 4-pin AC micro connector with M12 connection type provides fast, secure field wiring. Licensed electricians and industrial controls technicians are the primary installers of this device.

This limit switch is used in industrial and commercial automation applications including conveyor systems, machine tool controls, material handling equipment, and process machinery. The top-mounted parallel roller plunger actuator suits installations where the actuating surface approaches along the axis of the plunger. The operating temperature range of -40 degrees F to 220 degrees F allows deployment in both cold storage environments and high-heat industrial settings. NEMA ratings of 1, 2, 4, 6, and 6P confirm suitability for indoor, outdoor, and submersible duty locations.

Key Features

• SPDT contact form with NC configuration for direct integration into safety and control circuits
• Top-mounted parallel roller plunger actuator for linear approach actuation
• IP67-rated metal body resists dust ingress and temporary submersion
• M12 4-pin AC micro connector for tool-free, repeatable wiring connections
• NEMA 1, 2, 4, 6, and 6P rated for broad environmental duty coverage
• Maximum operating force of 80 ounces suits moderate to heavy actuating loads

Compatibility

Designed as an OEM-style replacement or direct installation limit switch for industrial control panels and automated machinery requiring a top-actuated SPDT roller plunger switch with M12 connectivity and IP67 environmental protection.

Installation Notes

Installation should be performed by a qualified electrician or controls technician in accordance with NEC Article 430 and applicable machine safety standards. De-energize and lock out the equipment before mounting or wiring the switch. The M12 connector must be fully seated and torqued to the connector manufacturer specification to maintain the IP67 seal. Verify actuator alignment and travel before returning the system to service to prevent premature mechanical wear.
