Square D 9007C62C Limit Switch Dpdt 2NC/2NO Rotary Head 600V

Product Description

The SQUARE D 9007C62C is a general purpose limit switch designed for industrial and commercial control applications requiring reliable position detection. It features a DPDT (double-pole, double-throw) contact configuration with 2NC/2NO contacts and a rotary head actuator mounted on the side of the unit. Rated for up to 600 volts, it carries an IP67 ingress protection rating, making it suitable for wet and dusty environments. The body is constructed from zinc for durability. Side screw terminals simplify field wiring. Licensed electricians and industrial control technicians are the primary installers for this device.

The 9007C62C is used in industrial automation, machine tool, conveyor, and process control applications where accurate actuator position sensing is required. The rotary head allows for consistent trip angle actuation, with a travel range of 45 degrees. Its wide operating temperature range of -20 degrees F to 185 degrees F makes it appropriate for both indoor and outdoor installations where environmental exposure is a concern. The IP67 rating supports use in washdown or high-moisture environments typical in food processing, packaging, or outdoor machinery.

Key Features

• DPDT contact form with 2NC/2NO configuration for flexible circuit control
• Rotary head actuator with side mounting and 45-degree travel range
• 600-volt rating supports a wide range of industrial control circuits
• IP67 ingress protection rated for dust-tight and temporary submersion resistance
• Zinc body construction for mechanical durability in demanding environments
• Compliant with IEC 60529, IEC 61140, and RoHS standards

Compatibility

Designed as an OEM-style replacement or direct-install general purpose limit switch for industrial control panels, machine tools, and automated equipment requiring DPDT rotary head actuation at up to 600 volts.

Installation Notes

Installation should be performed by a licensed electrician or qualified industrial controls technician in accordance with the NEC and applicable local codes. De-energize and lock out the circuit before making any wiring connections at the screw terminals. Verify actuator alignment and travel engagement before returning the system to service. Do not exceed the rated voltage or operating temperature limits.
