Square D 9001KN218 Metal Legend Plate Jog 30mm

Product Description

The SQUARE D 9001KN218 is a metal legend plate marked with the designation Jog, designed for use with 30mm pushbutton operator assemblies in industrial control panels. The plate features a black background with white letters for high-contrast readability in demanding shop-floor and machine-control environments. Made from metal construction, it provides durability over continuous use compared to plastic alternatives. Electricians and industrial control technicians install these legend plates to clearly label pushbutton functions, reducing operator error during machine setup and run operations. The plate measures 1.6 inches by 1.6 inches with a depth of 0.1 inches and weighs approximately 0.01 pounds.

This legend plate is suited for industrial and commercial applications where pushbutton stations require clear function labeling. Typical installations include motor control centers, machine tool panels, conveyor controls, and operator interface stations that use 30mm pushbutton assemblies. The Jog marking specifically identifies buttons used for inching or jogging motor operations, a common requirement in manufacturing and process control environments. Panel builders, electricians, and maintenance technicians working on UL 508A-compliant industrial control panels will find this plate a standard component in pushbutton labeling kits.

Key Features

• Metal construction for durability in industrial panel environments
• Jog legend marking for clear pushbutton function identification
• Black background with white letters for high-contrast visibility
• 30mm hole diameter fits standard 30mm pushbutton operator assemblies
• Compact footprint at 1.6 inches by 1.6 inches by 0.1 inches

Compatibility

Designed for use with 30mm pushbutton assemblies as stated by the manufacturer. Consult the SQUARE D 9001K series documentation to confirm fitment with specific pushbutton operators and mounting hardware before installation.

Installation Notes

Installation is performed by qualified electricians or industrial control panel builders in accordance with NEC and applicable local codes. De-energize the control panel and follow lockout/tagout procedures before accessing any pushbutton station. Legend plates are typically snapped or fastened onto the pushbutton operator body after the operator is mounted in the panel cutout. Verify the plate seats flush and the legend is oriented correctly before returning the panel to service.
