Square D 8965DPR23V14 24 VAC 25 Amp Polyphase 3-Pole Open Type Reversing Definite Purpose Hoist Contactor

Product Description

The Square D 8965DPR23V14 Reversing Hoist Contactor is designed for use in controlling hoists, overhead doors, small elevators, and commercial laundry equipment. This reversing contactor can handle short-duty operations, efficiently performing during the jogging cycles typical in hoist applications. It features a three-pole configuration with motor ratings of up to two horsepower at one hundred fifteen volts alternating current (VAC) and three horsepower at two hundred thirty VAC for single-phase systems. In polyphase configurations, it can be rated for five horsepower at two hundred thirty VAC and ten horsepower at four hundred sixty and five hundred seventy-five VAC.

• Rated for 24 VAC operation at 50/60 Hz.
• Compact dimensions of three point ninety-eight inches in height, five point eighty-seven inches in width, and three point zero seven inches in depth.
• UL component recognized and CSA certified for reliable and safe operation.

Product Highlights

This contactor is designed for flexibility with a replaceable coil available in various voltages. It does not come with an enclosure, and auxiliary contacts can be added as needed for expanded functionality.

Product Information

Standard Information

• Brand: Square D
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: 8965DPR23V14
• Voltage Rating: 600 Volt
• Amperage Rating: 25 Amp
• Coil Voltage: 24@50/60Hz VAC
• Number of Phases: 3 Phase
• Contact Configuration: 3-POLE
• Country of Origin: China
• Warranty Length: 18 months
