Square D 8911DPSO23V09 Definite Purpose Starter 25 Amp 20 Hp 3-Pole 208 to 240 VAC

Product Description

The Square D 8911DPSO23V03 Magnetic Motor Starter is specifically designed for rigorous industrial applications such as running air compressors, agricultural equipment, pumps, and HVAC devices. It functions optimally across multiple phases and electric voltages, ensuring reliable operation with a substantial 25 ampere full load capacity.

• Optimized for polyphase motors: capable of handling motors up to 20 HP.
• Robust three-pole design, enhancing power efficiency and safety.
• Thermal-melting alloy for overload protection, ensuring long-term reliability.

Product Highlights

This starter is UL component recognized, featuring non-replaceable coils across a range of voltages, supporting 220/208 to 240 VAC applications.

Product Information

Standard Information

• Height: 6.73 inches
• Width: 3.50 inches
• Depth: 4.09 inches

Technical Specifications

• Voltage: 208/240 VAC at 60 Hz, 220 VAC at 50 Hz
• Amperage: 25A
• Number of Poles: 3
• Enclosure Type: Open, without enclosure
• Warranty: 18 month contractual warranty
