Square D 8536SCO3V03 Motor Starter 240V 27A 3 Pole Open

Product Description

The Square D 8536SCO3V03 motor starter is engineered for full voltage control of AC motors, ensuring reliable startup and shutdown. As a NEMA Size 1 configuration, this 3-pole non-reversing starter features a 27 Amp current rating and supports three-phase power systems. This model uses a melting alloy type overload relay, employing Type B thermal units for accurate current sensing, presenting a solid solution for motor-driven applications without a protective enclosure.

• Power capacity reaches up to 10 HP on 460 and 575 VAC, suitable for heavy machinery.
• Operating coil voltage ranges between 220 VAC at 50 Hz and 240 VAC at 60 Hz, providing flexibility in usage.
• UL listed and CSA certified, ensuring adherence to North American safety standards.

Product Highlights

Designed for rigorous industrial environments, this motor starter is crafted without an enclosure to fit easily into existing setups. It has been constructed to withstand challenging conditions while maintaining high performance. The starter's dimensions are 6.77 inches tall, 3.50 inches wide, and 4.22 inches deep, making it compact yet robust for industrial demands.

Product Information

Standard Information

• Brand: Square D
• MPN: 8536SCO3V03

Technical Specifications

• Type: Motor starter; No control units
• Size: NEMA Size 1
• Current: 27 Amp
• Voltage: 600 VAC
• Phase: 3 Phase
• Number of Poles: 3 Pole
• Enclosure: NOT RATED (OPEN DEVICE)
• Country of Origin: USA
