Square D 8501XO40V02 AC Operated Control Relay 110/120 VAC (4NO) Replacement MPN

Product Description

The Square D 8501XO40V02 is an AC operated control relay designed for reliable performance in automation systems. This model operates at 110/120 VAC with a 10 ampere continuous current rating. It features a modular design, allowing for easy contact replacement without the need for rewiring.

• Four normally open contacts for enhanced functionality.
• Plug-in contact cartridges simplify maintenance tasks.
• UL listed and CSA certified for safety assurance.

Product Highlights

This control relay is optimized for applications requiring high durability and long operational life.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Brand: Square D

Technical Specifications

• Catalog Number: 8501XO40V02
• Product ID: 97383
• Coil Voltage: 110 V AC 50 Hz; 120 V AC 60 Hz
• Current Rating: 10 Amperes
• Contact Configuration: 4 normally open
• Dimensions: 3.95 inches depth, 2.23 inches width, 3.5 inches height
• Weight: 2.16 lbs
• Country of Origin: Mexico
• Operating Temperature: -40 to 160 degrees F
• Warranty Length: 18 months
